Bogi-Bars (Nose Wheel Aircraft Tow Bar)

Bogi-Bars (Nose Wheel Aircraft Tow Bar)

Bogert Aviation

  • $ 27000



Bogi Bars stay on until you take them off

Benefits & Features

  • Combination of steel used for durability.
  • Foam rubber hand and lever grips standard.
  • High shear quick release pins adjust length.
  • Powder coating process resists scratches.
  • Lifetime guarantee when used for the intended purpose.
  • Made in the USA.

    Operation

    • Extend handle using a quick release pin.
    • Open the jaws by pressing forward on the spreader lever.
    • Position feet at the nose or tail wheel assembly.
    • Release tension on spreader bar to lock on the bogi-bar.



    Videos

        Model # Nose Wheel Aircraft Price Extended Length Weight (lbs)
        04M-Aerostar Aerostar 601 $270 67 7
        04M-601XL AMD 601XL (Extra long wheel pants) $171 67 7
        04M-601Z AMD 601Z $171 67 7
        04M-Augusta Augusta Helicopter $285 67 7
        04M-35 Beechcraft - Baron, Bonanza, Debonair, Duchess, Duke, Skipper & T-34A. Fits 1/4" Strut Pin. $156 48 5
        04M-19/23B Beechcraft - Musketeer, Sport, Super, Sundowner, Sierra $156 48 7
        04M-B90 Beechcraft - Twin Beech, King Air, Queen Air $156 48 5
        04M-17/30 Bellanca - Viking $156 48 5
        04M-172 Cessna 150, 152, 162, 172, 175, 177, 182 Also RV-4 $156 48 5
        04M-182-XL Cessna 182 S (1996 and up) and T (2001 and up) models with long nose. Towbar extends to 55" and closes down to 35". $172 55 5
        04M-210 Cessna 172RG, 177RG, 182RG & 210 series, Skymaster $195 48 7
        04M-206 Cessna 205, 206 & 207 $156 48 5
        04M-Lance Cessna Corvalis, Lance/Columbia 350/400 $270 48 5
        04M-CH701 CH 701 Trainer $156 48 5
        04M-SR Cirrus SR 20 & 22 Series $156 48 5
        04M-DA20 Diamond DA20 $156 48 5
        04M-DA40 Diamond DA40 $156 48 5
        04M-DA42 Diamond DA42 $285 67 7
        04M-GLA-III Glassair III $202 48 5
        04M-AA Gulfstream American AA1 & AA5. AMD CH2000 $156 48 5
        04M-IAR 823 IAR 823 $202 48 5
        04M-Jabiru Jabiru Sport Aircraft $156 48 5
        04M-Kfox Kit Fox $156 48 5
        04M-Lake Lake Amphibian (LA-4) $202 48 7
        04M-LaRG Lancair RG Kit Plane $270 48 5
        04M-Moon Mooney Aircraft $156 48 5
        04M-24/30 Piper Comanche PA-24, PA-30 & PA-39 Also PA-32 Cherokee Six axle w/pants if tabs above wheel are broken (Not verified for Piper Saratoga with fixed gear) $156 48 5
        04M-LGCUB Piper Legend Cub $156 48 5
        04M-PA46 Piper PA46 Handpull for dog-leg style gear. Also fits Saratoga, PA-28R, Malibu, Mirage, Meridian $285
        60
        9
        04M-22/28 Piper PA-22 & PA-28 series (not PA-28R) Also, PA-32 Cherokee Six if attach tabs above wheel are still there. $156 48 5
        04M-28R Piper PA-28R Series - Hand pull for dog-leg style gear. Also fits Saratoga, PA-46, Malibu, Mirage, Meridian $285 60 9
        04M-32R Piper PA-32R-RT/Saratoga - Hand pull for dog-leg style gear, also fits Piper PA-28R Series, PA-46, Malibu, Mirage, Meridian $285 60 9
        04M-34 Piper Seneca PA-34-200/220/220T *handle extends to 67" $270 67 5
        04M-38 Piper Tomahawk $156 48 5
        04M-ROCK Rockwell 112 & 114 $156 48 5
        04M-March SIAI Marchetti $202 67 7
        04M-Socata Socata $156 48 5
        04M-RVA Vans - RV6A, RV7A, RV8A & RV9A, RV12, RV12* /*W/O wheel pants—pants in development at Vans 2/19/10 $156 48 5
        04M-RV10 Vans - RV10 $156 48 5
        04M-601CH Zodiac CH601 Kit Plane $156 48 5
        04M-StingS3 TL-Ultralight Sting S3 $156 48 5
        04M-GLA-NW Glasair GlaStar and Sportsman towbar (nose wheel configuration) $156 48 5
        04M-Tecnam Tecnam $182 48 5
        04M-Landis Landis Heavy Duty Nose Fork Towbar. Attaches to axle cup. $172 55 7
        04M-Airglas Airglas Heavy Duty Nose Fork Towbar. Attaches to axle cup. $172 55 7

        Customer Reviews

        Based on 23 reviews
        83%
        (19)
        13%
        (3)
        0%
        (0)
        0%
        (0)
        4%
        (1)
        J
        J.M.
        It just works

        I have purchased 3 Bogi-Bars for two different airplanes, an RV4 and RV9A. They work great and I wouldn't be without them.

        K
        K.N.
        Tow bar

        The tow bar we bought from Bogart is great. It's light enough for hauling and use but is strong enough to easily move a C182. It's increased length keeps us from being underneath the prop and nose cone. I wrapped some protective material on the front tongs to prevent metal-to-wheel pant contact. I think this would be a nice addition as the unit is being made.

        Thanks for the American Made product.

        D
        D.Q.
        Good fit

        The bars fit very well. I would like them to be a little bit longer. Also, the metal seems a little cheap for the price of the bars.

        Daniel, There is nothing cheap about the tubing we use. We use 4130 Chromoly tubing for everything except the lever and link. It's light weight and strong. We warranty them for life.
        E
        E.F.
        Vans RV6A towbar

        Works well for pulling, ok for steering when pushing backward. Would be better if stiffer (less flexible).

        Erik, The standard Bogi-bar is very strong pulling in tension but like any light weight structure, it is weaker in compression. If you want to push the airplane with the tow bar, you should take a look at our BBU model. It was designed to push and pull aircraft.
        T
        T.W.
